Abrasive roll slitter Machine
5000-7000 USD ($)/Set
Product Details:
- Shape Roll to strip slitting, produces linear strips
- Grain Type Aluminum oxide, Silicon carbide, Zirconia, Ceramic grains
- Toughness Designed for high durability and heavy-duty industrial applications
- Hardness Handles from flexible to semi-rigid abrasive sheets
- Chemical Composition Depends on abrasive and backing; machine has high strength steel composition
- Backing Paper, Cloth, Polyester, Combination Backing
- Bonding Suitable for resin-bonded and glue-bonded materials
- Click to View more
X
Abrasive roll slitter Machine Price And Quantity
- 5000-7000 USD ($)/Set
- 1 Set
- 0.15 - 7000.00 USD ($)/Set
Abrasive roll slitter Machine Product Specifications
- Width up to 1650 mm, Diameter up to 500 mm
- Adjustable, typically 10 mm to 300 mm wide
- Designed for high durability and heavy-duty industrial applications
- Aluminum oxide, Silicon carbide, Zirconia, Ceramic grains
- Handles from flexible to semi-rigid abrasive sheets
- Suitable for resin-bonded and glue-bonded materials
- Steel machine body, suitable for abrasive paper and cloth rolls
- Paper, Cloth, Polyester, Combination Backing
- Automatic Abrasive Roll Slitter
- Can slit rolls with various commercial grit sizes (P24P600+)
- Roll to strip slitting, produces linear strips
- Depends on abrasive and backing; machine has high strength steel composition
Abrasive roll slitter Machine Trade Information
- 1000 Set Per Month
- 30 Days
Product Description
Abrasive roll slitter Machine
The abrasives roll slitting machine is designed to slit abrasive rools into narrow rolls, It is highly efficient and easy to operate. This abrasive roll slitter machine with very good quality and its configuration and workmanship are also different with other companies' machines. After so many years of continuous improvement, we own the best assembly ability, no matter the main parts or the accessory parts we adopt international famous brand, and our factory's management and equipment's quality can compare with any abrasive roll slitter machine factories in China.
Abrasive roll slitter's technical parameters:
- Model: SLT-R-1750
- Slitting Range:100-1700mm
- Slitting Speed: 5-10m/min
- Slitting Pressure: 6-60kgf
- Slitting Accuracy ±0.5mm:
- Power: 7.5KW
- Air Pressure: 7.5MPa
- Voltage: 380V
- Size(L x W x H)(mm): 3900x3000x3000
- Weight: 1800kg
Abrasive roll slitter's application:
- The abrasives roll slitting machine is designed to slit abrasive rools into narrow rolls.
- Pneumatic feeding.
- Automatic deviation correction system.
- Easy to operate and maintain.
Abrasive roll slitting machine's advantage:
- Our company's management and equipment's quality can compare with any abrasives roll slitting machine factories in China.
- Improve abrasive belt production efficency and save time and effort.
- Main parts of the machine have one year warranty.
- Engineers are available to service overseas.
Advanced Cutting Precision
With a precision of 0.5 mm strip width and minimum cutting width as narrow as 10 mm, this slitter delivers consistent results for demanding abrasive conversion processes. The machine utilizes hardened high-speed steel or tungsten carbide blades, specifically chosen to maintain enduring accuracy and performance, ensuring every strip matches specified requirements without material waste.
Versatile Material Compatibility
Catering to a broad spectrum of abrasive products, the machine is suitable for resin-bonded and glue-bonded abrasive papers and cloth. It easily handles various grain typesaluminum oxide, silicon carbide, zirconia, and ceramicacross commercial grit sizes from P24 to P600+. Its structurally durable steel body and adaptable design make it an ideal tool for different backing materials, including paper, cloth, and polyester.
User-Friendly Automation
Equipped with a PLC-controlled system and a touch screen interface, the roll slitter streamlines operation and process monitoring. Operators can adjust desired strip widths, cutting speed, and tailor settings for roll sizes up to 1650 mm wide, enhancing efficiency while maintaining safety. Automation boosts overall productivity, reduces manual intervention, and ensures repeatable, high-quality output.
FAQs of Abrasive roll slitter Machine:
Q: How does the Abrasive Roll Slitter Machine operate to slit abrasive rolls?
A: This machine automatically feeds jumbo rolls of abrasive paper or cloth material and slits them into linear strips. The operator sets strip width and desired cutting speed via its touch screen PLC interface; high-speed steel or tungsten carbide blades then make precision cuts, producing consistent strips suitable for conversion processes.Q: What types of abrasive materials and grit sizes can the machine process?
A: It supports a wide range of abrasive types, including resin-bonded and glue-bonded paper or cloth, backed with materials such as polyester or combinations. The machine handles various grain types, like aluminum oxide, silicon carbide, zirconia, and ceramic, and accommodates commercial grit sizes from P24 to P600+.Q: When should the cutting speed be adjusted and how is it done?
A: Cutting speed, adjustable between 10 and 40 meters per minute, can be changed using the touch screen PLC controls. Adjustment depends on roll thickness, backing rigidity, and desired production outputslower speeds for tougher or thicker materials, and higher speeds for standard conversion operations.Q: Where is this machine best used in an industrial setup?
A: The Abrasive Roll Slitter Machine is designed for manufacturers, distributors, exporters, and traders in abrasive product industries. It is ideal for use in production lines converting jumbo rolls into strips for further processing, packaging, or retail, especially suited to heavy-duty industrial environments.Q: What benefits do PLC controls and automation bring to the slitting process?
A: The PLC control system simplifies set-up and monitoring, reducing operator workload while maintaining precise strip widths and uniform output. Automation enables safe, repeatable cuts, minimizes human error, and increases throughput, ultimately improving efficiency and production consistency.Q: How does the machine handle different roll sizes and strip widths?
A: Operators can configure the machine to process rolls up to 1650 mm in width and 500 mm in diameter, with strip widths adjustable from 10 mm to 300 mm. The robust steel body and adaptable mechanisms ensure smooth handling of heavy rolls, up to 300 kg, and accurate slitting regardless of material flexibility.Q: What advantages does this slitter offer over manual slitting for abrasive materials?
A: Compared to manual methods, the automatic slitter machine offers higher cutting accuracy, faster throughput, and greater safety. Its automated blade and feed systems reduce labor requirements, deliver consistent strip quality, and can tackle harder, heavier, and larger rolls with ease.Tell us about your requirement
