Abrasive Belt Skiving Machine with Auto Gluing
5000-7000 USD ($)/Set
Product Details:
- Backing Supports Cloth, Polyester, Paper-backed belts
- Shape Rectangular (belt form)
- Chemical Composition High-strength alloys and engineered plastics
- Bonding Automatic Gluing Integration
- Hardness Optimized for standard abrasive belt operations
- Grain Type Aluminum Oxide, Zirconia, Silicon Carbide, Ceramic
- Toughness Designed for industrial continuous operation
- Click to View more
X
Abrasive Belt Skiving Machine with Auto Gluing Price And Quantity
- 0.15 - 7000.00 USD ($)/Set
- 1 Set
- 5000-7000 USD ($)/Set
Abrasive Belt Skiving Machine with Auto Gluing Product Specifications
- 16 - 1200 grit supported
- High-strength alloys and engineered plastics
- Supports Cloth, Polyester, Paper-backed belts
- Rectangular (belt form)
- Designed for industrial continuous operation
- Variable, adjustable for different belt widths
- Optimized for standard abrasive belt operations
- Aluminum Oxide, Zirconia, Silicon Carbide, Ceramic
- Customizable as per requirement
- Alloy Steel, High-Grade Industrial Materials
- Automatic Gluing Integration
- Automatic Abrasive Belt Skiving and Gluing Machine
Abrasive Belt Skiving Machine with Auto Gluing Trade Information
- 1000 Set Per Month
- 30 Days
Product Description
To provide utmost satisfaction to our clients, we have been engaged in offering supreme grade Abrasive Belt Skiving Machine With Auto Gluing. It is a multi-function machine that is mainly used for sanding belt joint edge skiving and glue coating and film taping purpose. Offered machine is highly cherished among clients owing to its excellent working, low power consumption, robust construction, and corrosion resistant surface. Provided machine is made in accordance with the latest innovative techniques under the supervision of our deft professionals at the modern production unit. Apart from this, offered Abrasive Belt Skiving Machine With Auto Gluing is available in different specifications.
Technical Specification
- Skiving variable speed: 30-200mm/s
- Automatic operation and continuous feed
- Automatic gluing and automatic pasting film
- Dust catcher: 1
- Skiving mode: diamond wheel, abrasive belts, steel brush
- Locking roll: pneumatic
- Installed power: 10 KW
- Pneumatic Pressure: 0.7 Mpa
- Overall machine dimensions: 3x0.7x1.6m ( L x W x H)
- Approx. weight: 1600kg
Efficient Belt Preparation and Gluing
This machine streamlines abrasive belt production by integrating belt skiving and gluing processes, enabling high-throughput outputup to 800 belts per 8-hour shift. Adjustable skiving width and angle ensure compatibility with various belt designs, while the automatic glue application promotes uniform adhesive distribution for reliable bonding.
Advanced Control and Safety Features
Equipped with a user-friendly touchscreen HMI and PLC system, operators can precisely set parameters and monitor all functions. Safety is prioritized through emergency stops, a transparent protective cover, and overload protection, creating a secure working environment for continuous industrial operation.
Versatility Across Applications and Materials
The machine is compatible with a broad array of abrasive grains (Aluminum Oxide, Zirconia, Silicon Carbide, Ceramic) and backings, including cloth, polyester, and paper. Rolls and strips sizes are customizable, meeting the demands of manufacturers, distributors, and exporters working with different abrasive belt requirements.
FAQs of Abrasive Belt Skiving Machine with Auto Gluing:
Q: How does the abrasive belt skiving and gluing process work on this machine?
A: The machine first skives, or bevels, the ends of abrasive belts to precise angles and widths according to your settings. It then automatically applies water-based or solvent-based adhesive onto the skived surface, ensuring uniform glue spread before the belt joint is completed.Q: What belt sizes and types can the machine handle?
A: It accommodates skiving widths from 10mm to 150mm, a maximum belt thickness of up to 10mm, and supports abrasive grains ranging from 16 to 1200 grit. The system can process belts backed with cloth, polyester, or paper, as well as various abrasive grains including Aluminum Oxide, Zirconia, Silicon Carbide, and Ceramic.Q: When should routine maintenance be performed on the machine?
A: Routine maintenance intervals depend on usage intensity, but daily inspection and cleaning are recommended. The automatic centralized lubrication system helps reduce manual maintenance, ensuring essential moving parts stay well-oiled for optimal machine performance.Q: Where is this machine typically used?
A: This machine is primarily used in industrial settings, such as abrasive belt manufacturing and coated abrasive conversion workshops. It is suitable for use by distributors, exporters, suppliers, manufacturers, and traders seeking high-output, reliable abrasive belt joint preparation.Q: What are the key advantages of using this skiving and auto gluing machine?
A: The main benefits include increased production efficiency (up to 800 belts per shift), consistent and precise skiving and gluing, improved adhesive integrity at the belt joint, enhanced operator safety, and compatibility with a wide range of abrasive materials and belt sizes.Q: How does the speed adjustment feature enhance operation?
A: The inverter-controlled variable speed drive allows operators to adjust processing speed according to belt material and adhesive type. This ensures optimal skiving and gluing for different production requirements while maintaining product quality and reducing material wastage.Tell us about your requirement
