Narrow Abrasive Belt Slitting Machine
5000-7000 USD ($)/Set
Product Details:
- Toughness Industrial grade, heavy-duty construction
- Grain Type Aluminum Oxide, Zirconia Alumina, Silicon Carbide, Ceramic
- Bonding Resin Bonded Abrasive Compatible
- Hardness Compatible with various belt hardness grades
- Chemical Composition Non-reactive body with industrial protective coatings
- Shape Rectangular/strip output
- Backing Cloth, Paper, Polyester, or Combination
- Click to View more
X
Narrow Abrasive Belt Slitting Machine Price And Quantity
- 5000-7000 USD ($)/Set
- 0.15 - 7000.00 USD ($)/Set
- 1 Set
Narrow Abrasive Belt Slitting Machine Product Specifications
- 36 to 1200 (as per abrasive belt type)
- Compatible with various belt hardness grades
- Cloth, Paper, Polyester, or Combination
- Stainless Steel / Mild Steel frame
- Standard 1650 mm (customizable)
- Rectangular/strip output
- Non-reactive body with industrial protective coatings
- Automatic Narrow Belt Slitting Machine
- Industrial grade, heavy-duty construction
- 3 mm to 100 mm adjustable
- Resin Bonded Abrasive Compatible
- Aluminum Oxide, Zirconia Alumina, Silicon Carbide, Ceramic
Narrow Abrasive Belt Slitting Machine Trade Information
- 1000 Set Per Month
- 30 Days
Product Description
We are immensely appreciated by our clients for manufacturing and exporting top quality Narrow Abrasive Belt Slitting Machine. This machine is known for its automatic process control. Offered machine is designed for slitting hard material such as abrasive belt and other related items. Provided machine finds its usefulness in commercial and industrial places for cutting purpose. This machine is coated with supreme quality paint to prevent it from rust. In addition to this, provided Narrow Abrasive Belt Slitting Machine can be purchased from us in numerous specifications as per clients demand.
Technical Specification
- Slitting belt width:10-400mm
- Slitting belt length: 340-1500mm
- Knife pressure (adjustable): 500Kgf
- Belt tensioning (adjustable): 120Kgf
- Installed power: 1.5 KW
- Pneumatic Pressure: 0.7 Mpa
- Overall machine dimensions : 1.2 x 1.1 x 0.9 m (L x W x H)
- Approx. weight: 800kg
Precision Engineering with Versatile Control
Experience unmatched control and precision in abrasive belt slitting. This machines PLC touch screen and on-the-fly digital counter enable seamless operation. The slitting precision of 0.2 mm guarantees consistently accurate output, while variable speed adjustment (030 m/min) accommodates diverse production needs. Its advanced drive motors (2.2 kW4 kW) and pneumatic tension options for unwinding/rewinding ensure high efficiency for both short and long production runs.
Wide Compatibility and Robust Construction
Manufactured with a heavy-duty stainless steel or mild steel frame, this slitting machine is built for rigorous industrial use. It processes belts with widths up to 1650 mm and supports various abrasive grains like Aluminum Oxide, Zirconia Alumina, Ceramic, and Silicon Carbide. Compatible with a range of backingscloth, paper, polyester, or combinationsit provides flexibility for different abrasive belt types and bonding structures.
Enhanced Safety and Customization
Safety is engineered into every detail, with features like emergency stop, overload protection, and secure safety covers. The customizable power supply (380V/50Hz/3Phase and others) and adaptable roll sizes make the machine suitable for global export and varying operational requirements. Low noise operation (<78 dB[A]) and robust protective coatings support comfortable and sustainable workplace environments.
FAQs of Narrow Abrasive Belt Slitting Machine:
Q: How does the Narrow Abrasive Belt Slitting Machine achieve precise slitting widths?
A: The machine uses a high-precision PLC touch screen control system combined with digital counters and carbide alloy slitting blades. This ensures a slitting precision of 0.2 mm, making it suitable for consistent and accurate narrow strip production.Q: What range of belt sizes and abrasive grains can this machine handle?
A: It can process input rolls up to 1650 mm wide, with slitting widths from 3 mm to 100 mm adjustable. The machine supports abrasive grain sizes from 36 to 1200, compatible with Aluminum Oxide, Zirconia Alumina, Silicon Carbide, and Ceramic grains.Q: When should variable speed control be used, and what are its benefits?
A: Variable speed control (030 meters per minute) allows operators to adjust the slitting speed based on the type of abrasive material and production requirements. This flexibility increases efficiency and reduces wear on the blades and backing materials.Q: Where is this machine commonly used in the industry?
A: The slitting machine is widely used in the manufacturing of sanding belts and strips for woodworking, metalworking, and other industrial sectors where precision abrasive processing is critical.Q: What is the typical process for slitting abrasive belts with this machine?
A: Operators load abrasive rolls onto the air shaft, select the desired width and speed using the touchscreen, and initiate the process. The machine maintains accurate slitting with digital counters and pneumatic tension controls for smooth unwinding and rewinding.Q: How does the machine ensure operator and workplace safety?
A: It is equipped with safety features such as emergency stop buttons, protective covers over moving parts, and overload protection, minimizing risk during operation and maintenance.Q: What are the main advantages of using this automatic narrow belt slitting machine?
A: Key advantages include high slitting precision, versatility in material and width settings, robust industrial build, reduced manual intervention, efficient speed control, compatibility with a range of abrasive backings and grains, as well as enhanced safety for continuous production.Tell us about your requirement
