Full automatic Cutting Disc Making Machine

5000-7000 USD ($)/Set

Get a Price/Quote

Product Details:

Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Price And Quantity

Price Range 0.15 - 7000.00 USD ($)/Set
Price 5000-7000 USD ($)/Set
Minimum Order Quantity 1 Set

Trade Information

Supply Ability 1000 Set Per Month
Delivery Time 30 Days

Product Description

With 28 years of experience in this domain, we are involved in offering supreme grade Full automatic Cutting Disc Making Machine. This machine is well admired among clients owing to its trouble-free working, less maintenance, and robust construction. Offered machine is equipped with the latest motor and all necessary components which ensure its smooth working. Provided machine is tested on different parameters before final dispatch for ensuring flawless delivery to clients. Apart from this, offered Full automatic Cutting Disc Making Machine is available in different specifications as per clients demand.

Technical Specification

Model	PRS-P40T125A45	PRS-P40T250A679	PRS-P16T400A1246
Grinding wheel diameter	100, 115, 125mm	150, 180, 230mm	300 350, 400mm
Grinding wheel thickness	1.0-7.0mm	1.0-7.0mm	2.5-4.0mm
Grinding wheel Hole	16/22.23mm	22.23mm	25.4/32 mm
Grinding wheel shape	T41/T27	T41 and T27	T41
Structure	Pusher type, multi-position, single-mode cavity	Pusher type, multi-position, single-mode cavity	Pusher type, multi-position, single-mode cavity
Rating press	100T/125T/200T	200T/250T/300T	300T/400T/500T
Control mode	PLC control, touch screen	PLC control, touch screen	PLC control, touch screen
Mould rotation speed	30-100R/Min (adjustable)	20-60R/Min (adjustable)	20-50R/Min (adjustable)
Each leveling micro-lift	Servo motor 0.05-3.0mm	Servo motor 0.05-3.0mm	Servo motor 0.05-3.0mm
Leveling mode	Scraper blades raising speed and process can be set freely.	Scraper blades raising speed and process can be set freely.	Scraper blades raising speed and process can be set freely.
Working beat	6-7sec per grinding wheel	9-12sec per grinding wheel	12-14sec per grinding wheel
Capacity	4200-4800pcs/ 8 hour	2400-3200pcs/ 8 hour	2100-2400pcs/ 8 hour
Operators	3-5 persons	3-5 persons	2-3 persons
Installed power	20KW (including heating power)	26KW (including heating power)	31KW (including heating power)
Consumption power	6-8KW	8-11KW	9-12KW
Size	4500x1650x2750mm	6000x1860x2900mm	2800x6900x2800mm
Weight	4800kgs	6800kgs	13000kg
